250m3/H Industrial Pipeline Water Pump Vertical Booster For High Rise Building

Product Details:
Place of Origin: China
Brand Name: APK
Certification: ISO; CE
Model Number: Pipeline Water Pump
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Please feel free to contact us
Packaging Details: Pipeline water pump is packed with wooden case or 20 inch container.
Delivery Time: 2-5 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1200 pieces per month

Detail Information

Head: 12m-160m Flow: 20m3h-1200m3/h
Voltage: 380v/440v Or As Per Request Power: 4kw-160kw
Frequency: 3 Phase 50hz/60hz Install: Vertical; Horizontal
High Light:

water supply booster pump

,

centrifugal booster pump

Product Description

250m3/h Industrial Vertical Booster Pipeline Water Pumps for High Rise Building



Pipeline water pump are for conveying water and chemical and physical properties of the other similar liquid, applicable to industrial and urban water supply and drainage, high-rise buildings, landscape pressurized water and fire sprinkler turbocharged, distant distance transportation, increase water changes the bathroom Pressure and temperature, the use of jockey pump less than 80 degrees.



SLW/SLG pipeline water pump overview:

SLW/SLG horizontal channel pump is for conveying water and other liquids whose physical properties similar to water. Using the medium below 80°C.

1. Flow: 20m3/h-1200m3/h

2. Head: 12m-160m

3. Power: 3kw-160kw

4. Outlet diameter: φ80-φ500mm

5. Temperature: 0~120℃

6. Vertical or Horizontal install



250m3/H Industrial Pipeline Water Pump Vertical Booster For High Rise Building 0



Pipeline water pump applications:

1) ISG/ISW centrifugal pipeline pressure test pump apply to high building water supply, garden irrigation, far distance water supply, etc. Using temperature < 45 degree.
A. Inlet hydraulic pressure less and equal to 0.3Mpa, more and equal to 0.2Mpa; B. water quality should be normal water without fibre or solid particle; C. medium temperature does not exceed 50 degree; D. supply must be 380v
2) Anti-explosion pipeline pressure test pump apply to the transportation of petroleum, chemical liquid, inflammable or explosive liquid without corrosivity. Using temperature < 80 degree.



3) Anti-corrosion and explosion pipeline pressure test pump allpy to the transportation of petroleum, chemical liquid, inflammable or explosive liquid with corrosivity. Using temperature < 140 degree.



250m3/H Industrial Pipeline Water Pump Vertical Booster For High Rise Building 1



Pipeline water pump parameters:

Model Flow Head Speed Power
SLG/SLW m3/h m r/min kw
20-160 1.8 33 2900 1.1
40-160 6.3 32 2900 2.2
40-200 8.3 48 2900 4
40-250 4.4 82 2900 7.5
50-250 12.5 80 2900 11
65-250 25 80 2900 15
65-315 32.5 122 2900 30
80-100 35 13.8 2900 3
80-125 50 20 2900 5.5
80-350 60 140 2900 55
100-100 130 11 2900 5.5
100-315 70 132 2900 75
100-350 130 148 2900 90
125-100 160 12.5 2900 11
125-125 96 22.6 2900 15
150-250 200 20 1450 18.5
150-315 260 28 1450 30
150-500 151 56 1450 45
150-315 240 120 2900 110
250-250 300 18.1 1450 45
250-500 660 68 1450 185
300-235 900 15 1450 55
300-250 540 22.5 1450 55
300-300 720 32 1450 90
300-400 500 54 1450 132
350-250 120 20 1450 90
350-400 1200 50 1450 110
350-400 905 31 1450 160



250m3/H Industrial Pipeline Water Pump Vertical Booster For High Rise Building 2
