Automatic Mixture Submersible Wastewater Pump 5-300m3/H Sewage Water Pump

Product Description

WQ-JY Flow 5-300m3/h Waste Dirty Water Automatic Mixture Submersible Sewage Pump

WQ-JY automatic mixture submersible sewage pump overview:

The pump has a stirring impeller except the impeller, it is adopt the automatic device, when the motor shaft spinning, can produce strong mixing force, syir the sewage sediments of the pool to a suspended solids, then drain the sewage water out.

1. Flow: 5-300m3/h
2. Head: 5-180m
3. Voltage: 380v/440v/460v or customized
4. Frequency: 3 phase 50hz/60hz
5. Power: 2.2kw-200kw
6. Caliber: φ25-φ400mm
7. Temperature: <40℃
8. Material: Cast iron or Stainless steel
9. Highly improve the sewage pump ability
10. On-time completed draiange and clean

WQ-JY submersible sewage pump applications:

This pump has stron passing ability and good cutting performance. It is widely used to deliver sewage water that contains long fiber, plestic bags, cloth straps, ropes, leaves,. It also works well in pumping clear water for irrigation or drainage.

WQ-JY submersible sewage pump overview:

WQ-JY submersible sewage pump parameters:

If these submersible sewage pump do not meet your demand, please feel free to contact us. We will choose one suitable model for you.

WQ-JY submersible sewage pump using condition:

1. Voltage 380V or 660V (allowance error: 5%), 50Hz, three-phase alternating-current supply
2. solid material volume ratio in pumped medium should be below 2%, Maximum pumped medium density is 1.2*103kg/ m3
3. PH value should be 4-12
4. Temperature should be not less than 50℃
