15kw 20hp Submersible Sewage Pump IP68 Cast Iron / Stainless Steel Material
  • name
  • name
  • name

15kw 20hp Submersible Sewage Pump IP68 Cast Iron / Stainless Steel Material

MOQ: 1 piece
Price: Please feel free to contact us
Standard Packaging: Submersible sewage pump is packed with wooden case or 20 inch container.
Delivery Period: 2-5 working days
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 8695 pieces per month
Detail Information
Product Description
Detail Information
Place of Origin
Henan, China
Brand Name
APK
Certification
ISO9001;ISO4001;ISO18001;CE,BV; TUV; SABER
Model Number
WQ
Head:
60m 30m 20m 15m 11m Submersible Sewage Pump
Flow:
30m3/h 100m3/h 130m3/h 180m3/h 250m3/h Submersible Sewage Pump
Power:
15kw 20hp Sewage Pump
Voltage:
220v/380v/440v Or As Per Request
Frequency:
3 Phase 50hz/60hz
Material:
Cast Iron/stainless Steel
Protection Class:
IP68
Motor:
Copper Wire
Highlight:

submersible sewage water pump

,

submersible dirty water pump

Product Description

15kw 20hp submersible sewage pump is maximum flow is 250m3/h, however, head is low. Main material is cast iron and stainless steel.



Our WQ sewage submersible pump is sewage pump developed on the basis of the introduction of foreign advanced technology. WQ series submersible sewage pump is power irrigation equipment united by the motor and the pump, especially the swirling impeller and double-channel impeller matched with spiral type centrifugal pump body, which have extremely strong drainage capacity.



The motor part adopts mechanical seals of hard corrosive double end face ceramic, which have very good effect of seepage prevention, its protection level is IP68 and designed insulation class is grade E, more rinning more safe, reliable, and long service life, convenient installation.



15kw 20hp submersible sewage pump overview:

  1. Flow: 30m3/h 100m3/h 130m3/h 180m3/h 250m3/h submersible sewage pump
  2. Head: 60m 30m 20m 15m 11m submersible sewage pump
  3. Power: 15kw 20hp submersible sewage pump
  4. Voltage: 220v/380v/440v or as per request
  5. Frequency: 3 phase 50hz/60hz
  6. Material: Cast iron/stainless steel

15kw 20hp Submersible Sewage Pump IP68 Cast Iron / Stainless Steel Material 0



15kw 20hp Submersible Sewage Pump IP68 Cast Iron / Stainless Steel Material 1



WQ submersible sewage pump parameters:



Model Outlet diameter (mm) Flow (m3/h) Head (m) Power (kw) Speed (r/min)
WQ50-18-30-3 50 18 30 3 2900
WQ50-40-15-4 50 40 15 4 2900
WQ50-25-32-5.5 50 25 32 5.5 2900
WQ50-20-40-7.5 50 20 40 7.5 2900
WQ65-25-15-2.2 65 25 15 2.2 2900
WQ65-25-30-4 65 25 30 4 2900
WQ65-30-40-7.5 65 30 40 7.5 2900
WQ65-35-50-11 65 35 50 11 2900
WQ65-35-60-15 65 35 60 15 2900
WQ80-43-13-3 80 43 13 3 2900
WQ80-40-15-4 80 40 15 4 2900
WQ80-65-25-7.5 80 65 25 7.5 2900
WQ100-110-10-5.5 100 110 10 5.5 1450
WQ100-100-15-7.5 100 100 15 7.5 1450
WQ100-80-20-7.5 100 80 20 7.5 1450
WQ100-100-25-11 100 100 25 11 1450
WQ100-100-30-15 100 100 30 15 1450
WQ125-130-15-11 125 130 15 11 1450
WQ125-130-20-15 125 130 20 15 1450
WQ150-150-13-11 150 150 13 11 1450
WQ150-180-15-15 150 180 15 15 1450
WQ200-300-7-11 200 300 7 11 1450
WQ200-250-11-15 200 250 11 15 1450



It is one part of 15kw 20hp submersible sewage pump parameters. If you would like to know more, please feel free to contact us.We will choose one suitable pump model for you.
