10 Hp Cast Iron Submersible Dirty Water Pump 220v / 380v Voltage Vertical Installation

MOQ:	1 piece
Price:	Please feel free to contact us
Standard Packaging:	Submersible sewage pump is packed with wooden case or 20 inch container.
Delivery Period:	2-5 working days
Payment Method:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity:	8578 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin

Henan, China

Brand Name

APK

Certification

ISO9001;ISO4001;ISO18001;CE,BV; TUV; SABER

Model Number

Power:

3kw/4kw/5.5kw/7.5kw Sewage Pump

Flow:

7-50m3/h

Head:

7-40m

Outlet Size:

50mm 65mm 80mm 100mm 150mm

Speed:

2900 Rpm

Voltage:

220v/380v

Material:

Cast Iron/stainless Steel

Install:

Vertical

ODM OEM:

Quality Warranty:

One Year Or More

Highlight:

submersible sewage water pump

submersible dirty water pump

Product Description

3kw/4kw/5.5kw/7.5kw 10 hp cast iron waste water sewage submersible pump

Sewage pump parameters:

Outlet size	Model	Flow	Head	Speed	Power
mm	WQ Types	m3/h	m	r/min	kw
50	50WQ7-15-1.1	7	15	2900	1.1
50	50WQ10-15-1.5	10	15	2900	1.5
50	50WQ10-22-2.2	10	22	2900	2.2
50	50WQ15-20-2.2	15	20	2900	2.2
50	50WQ15-25-3	15	25	2900	3
50	50WQ15-32-4	15	32	2900	4
50	50WQ18-40-5.5	18	40	2900	5.5
65	65WQ15-7-1.1	15	7	2900	1.1
65	65WQ25-7-1.5	25	7	2900	1.5
65	65WQ25-10-2.2	25	10	2900	2.2
65	65WQ25-20-3	25	20	2900	3
65	65WQ25-25-4	25	25	2900	4
65	65WQ30-30-5.5	30	30	2900	5.5
80	80WQ35-7-2.2	35	7	2900	2.2
80	80WQ50-10-3	50	10	2900	3
80	80WQ50-13-4	50	12	2900	4
80	80WQ40-22-5.5	50	13	2900	5.5
80	80WQ45-22-7.5	45	22	2900	7.5
100	100WQ50-6-2.2	50	6	2900	2.2
100	100WQ60-9-3	60	9	2900	3
100	100WQ60-10-4	60	10	2900	4
100	100WQ65-15-5.5	65	15	2900	5.5
100	100WQ100-10-7.5	100	10	2900	7.5
150	150WQ140-7-7.5	140	7	2900	7.5

Introduction of submersible sewage pump:

WQ submersible sewage pump is sewage pump developed on the basis of the introduction of foreign advanced technology. WQ series submersible sewage pump is power irrigation equipment united by the motor and the pump, especially the swirling impeller and double-channel impeller matched with spiral type centrifugal pump body, which have extremely strong drainage capacity.

The types of submersible sewage pump:

1. WQK cutting sewage pump: sewage water contains long fiber, plastic bags, cloth straps, ropes, leaves, etc.

2. WQ-JY automatic mixture sewage pump: it is adopt the automatic device, when the motor shaft spinning, can produce strong mixing force, stir the sewage sediments of the pool to a suspended solids

3. WQG non clogging sewage pump: mining exploration, wastewater discharge, underground chamber, sewage drainage.

4. WQX bottom suction sewage pump: pumping sewage and sludge in any severe environment

5. WQS water filled sewage pump: motor filled with water inside, cooling better, no pollution

6. WQP stainless steel sewage pump: sea water, salt water, corrosive medium

The features of submersible sewage pump:

1. Compact structure, easy to move, easy installation

2. Specially adopting cyclone type and double flow type impeller ( high lift pump adopts centrifugal type), strong pollution discharge capacity

3. The motor adopt hard corrosion-resistant single and double end face ceramic seal, good anti leakage effect, the motor running more safe and reliable.

10 Hp Cast Iron Submersible Dirty Water Pump 220v / 380v Voltage Vertical Installation 0
