AC 3 Phase Open Well Water Pump Submersible Borehole Water Pump 24 Months Warranty

Minimum Order Quantity : 1 piece Price : please kindly contact
Packaging Details : submersible water pump with Shock absorption,moisture-proof package, standard export wooden case Delivery Time : 7-15 working days after payment confirmed
Payment Terms : T/T , Western Union , L/C , D/A , D/P , MoneyGram Supply Ability : 10000 Unit/Units per Month
Place of Origin: Henan, China Brand Name: APK
Certification: CE; ISO9001; Five stars after-sale service Model Number: water submersible pump

Detail Information

Power: 10hp 15hp 20hp 30hp 40hp Submersible Water Pump Outlet Size: 2" 3" 4" 5" 6" 8"
Diameter: 7 8 10 12 14 Inch Submersible Pump Capacity: 9m3/h-540m3/h
Head: 12m-310m Frequency: AC 3 Phase 50hz/60hz
Voltage: 380v/440v/480v/600v/660v Or As Per Request Material: Cast Iron/SS304/SS316/SS316L/Duplex Stainless/SS904L
Warranty: 24 Months
High Light:

deep well submersible water pump

,

submersible deep well pumps

Product Description

10hp 15hp 20hp 30hp 40hp open well submersible water pumps 3 phase borehole water submersible pump



water submersible pump performance range:

* Pump diameter: 7 8 10 12 14 inch water submersible pump
* Flow: 9-540m3/h
* Lift: 14-325m
* Power: 15kw 18.5kw 22kw 30kw well submersible pump
* Voltage: 380v 440v 660v 1140v or as per request
* Frequency: 3 phase 50hz/60hz

* Material: Cast iron/stainless steel 304/316/316L/duplex stainless/super duplex stainless steel/SS904L


10hp 15hp 25hp 30hp 40hp water submersible pump parameters:

(cast iron or SS304/SS316/SS316L/duplex stainless/super stainless steel/SS904L and 380v/440v/480v/

600v/660v/1140v. If you would like to know more, please kindly contact us)

Diameter Model Power Flow range Head range
Inch(") QJ type kw hp m3/h m
7" 175QJ10-121/9 7.5 10 9-11 96-140
7" 175QJ10-180/13 11 15 9-11 173-187
7" 175QJ15-80/6 7.5 10 13-17 64-96
7" 175QJ20-104/8 11 15 18-22 89-120
7" 175QJ25-65/5 7.5 10 23-27 53-76
7" 175QJ25-91/7 11 15 23-27 75-105
7" 175QJ32-48/4 7.5 10 29-35 40-56
7" 175QJ32-72/6 11 15 29-35 60-80
7" 175QJ40-36/3 7.5 10 37-43 28-42
7" 175QJ40-60/5 11 15 37-43 50-70
7" 175QJ50-36/3 7.5 10 46-54 28-42
7" 175QJ50-48/4 11 15 46-54 40-56
8" 200QJ15-81/6 7.5 10 13-17 68-92
8" 200QJ20-162/12 18.5 25 18-22 138-187
8" 200QJ20-202/15 22 30 18-22 172-232
8" 200QJ20-270/20 30 40 18-22 230-310
8" 200QJ25-56/4 7.5 10 23-27 45-67
8" 200QJ25-84/6 11 15 23-27 67-100
8" 200QJ25-154/11 18.5 25 23-27 138-184
8" 200QJ32-48/3 7.5 10 29-35 38-58
8" 200QJ32-112/7 18.5 25 29-35 90-132
8" 200QJ32-130/10 22 30 29-35 108-155
8" 200QJ40-45/3 7.5 10 37-43 32-48
8" 200QJ40-104/8 18.5 25 37-43 89-124
8" 200QJ50-30/2 7.5 10 46-54 24-36
8" 200QJ50-75/5 18.5 25 46-54 60-90
8" 200QJ63-28/2 7.5 10 58-68 24-33
8" 200QJ80-22/2 7.5 10 74-86 19-25
8" 200QJ80-55/5 18.5 25 74-86 47-63
8" 200QJ100-15/1 7.5 10 80-120 12-16
8" 200QJ100-60/4 30 40 80-120 58-62
10" 250QJ50-33/2 7.5 10 46-54 28-38
10" 250QJ50-80/4 18.5 25 46-54 68-92
10" 250QJ50-120/6 30 40 46-54 102-138
10" 250QJ63-40/2 11 15 58-68 34-46
10" 250QJ80-20/1 7.5 10 74-86 17-23
10" 250QJ100-18/1 7.5 10 80-120 16-21
10" 250QJ125-32/2 18.5 25 116-134 27-37
10" 250QJ140-30/2 18.5 25 130-150 26-34
12" 300QJ240-22/1 22 30 223-257 18-25
12" 300QJ500-15/1 30 40 460-540 14-16
14" 350QJ250-25/1 30 40 233-267 22-28
14" 350QJ320-20/1 30 40 305-335 18-22



Applications:
1. Ground water pumping
2. Irrigation system
3. Sea water, shipyard, offshore, floating dock, salt water
4. Drawing water from well



Customer case:

40m3/h 36m 7.5kw 10hp 80 pieces water submersible pump to Kazakhstan

AC 3 Phase Open Well Water Pump Submersible Borehole Water Pump 24 Months Warranty 0





AC 3 Phase Open Well Water Pump Submersible Borehole Water Pump 24 Months Warranty 1







APK pump factory not only manufacture water pumps, but also manufacture match pump accessories, including pump control cabinet, frequency converter(ABB or as per request), cable, valve.

AC 3 Phase Open Well Water Pump Submersible Borehole Water Pump 24 Months Warranty 2



Package: the well pump has 3 layers of packaging with 8mm special export wooden box. Shock absorption, moisture-proof package.


AC 3 Phase Open Well Water Pump Submersible Borehole Water Pump 24 Months Warranty 3



FAQ:



1. What's your MOQ?



one piece



2. What's your deliver method?



Sea freight, express, airplane





3. What's your payment?



T/T
