185kw Submersible Pump Farmland Irrigation Stainless Steel
Contact Person : Destiny.Huang
Phone Number : 86 17537187726
WhatsApp : +8617537187726
| Minimum Order Quantity : | 1 piece | Price : | please kindly contact |
|---|---|---|---|
| Packaging Details : | Submersible pump with Shock absorption,moisture-proof package, standard export wooden case | Delivery Time : | 7-15 working days after payment confirmed |
| Payment Terms : | T/T | Supply Ability : | 10000 Unit/Units per Month |
| Place of Origin: | Henan, China | Brand Name: | APK |
|---|---|---|---|
| Certification: | CE; ISO | Model Number: | Water Submersible Pump |
|
Detail Information |
|||
| Pump Diameter: | 7 8 10 12 14 16 Inch Submersible Pump | Flow: | 10m3/h-850m3/h Water Submersible Pump |
|---|---|---|---|
| Head: | 100m 200m 300m Water Submersible Pump | Power: | 7.5kw-220kw Water Submersible Pump |
| Material: | Cast Iron/SS304/SS316/SS316L/SS904L | Outlet Size: | 2" 3" 4" 5" 6" 8" 10" |
| Install: | Vertical Water Submersible Pump | Speed: | 1450r/min, 2900r/min, 3450r/min |
| High Light: | Deep Well Borehole Submersible Pump,300m Head Borehole Submersible Pump,220kw Borehole Submersible Pump |
||
Product Description
It is a Youtube video about our factory strength, including pump production lines, quality control, spare parts warehouse to promise deliver time, and package. From raw material to spare parts to quality control to deliver, all is under control. If you would like to inquiry water submersible pump or get quotation, please kindly send inquiry. Whatever you are a distributor, end user, trading company or tender, wecome to inquiry with pump specifications requires.
The main part material cast iron submersible pump as below:
1. The pump impeller, pump casing coupling part and motor casing is cast iron material.
2. The pump shaft is stainless steel material.
3. The bearing is graphite.
4. The winding is 100% copper with polyethylene insulation layer.
5. The rotor end ring is copper.
6. The stator casing is with 45# steel.
7. The stator is cold rolling silicon steel.
100m 200m 300m water submersible pump models:
| Pump diameter | Model | Motor Power | Flow | Head | |
| Inch(") | QJ Series | kw | hp | m3/h | m |
| 7" | 175QJ10-150/11 | 9.2 | 13 | 44085 | 144-146 |
| 7" | 175QJ20-104/8 | 11 | 15 | 18-22 | 89-120 |
| 7" | 175QJ32-48/4 | 7.5 | 10 | 29-35 | 40-56 |
| 7" | 175QJ32-108/9 | 15 | 20 | 29-35 | 82-123 |
| 8" | 200QJ20-108/8 | 13 | 18 | 18-22 | 92-125 |
| 8" | 200QJ20-202/15 | 22 | 30 | 18-22 | 172-232 |
| 8" | 200QJ20-256/19 | 30 | 40 | 18-22 | 218-295 |
| 8" | 200QJ20-310/23 | 37 | 50 | 18-22 | 265-356 |
| 8" | 200QJ25-56/4 | 7.5 | 10 | 23-27 | 45-67 |
| 8" | 200QJ25-154/11 | 18.5 | 25 | 23-27 | 138-184 |
| 8" | 200QJ25-252/18 | 30 | 40 | 23-27 | 210-290 |
| 8" | 200QJ32-52/4 | 7.5 | 10 | 29-35 | 42-62 |
| 8" | 200QJ32-104/8 | 18.5 | 25 | 29-35 | 84-125 |
| 8" | 200QJ32-256/16 | 45 | 60 | 29-35 | 217-265 |
| 8" | 200QJ50-150/10 | 37 | 50 | 46-54 | 128-173 |
| 10" | 250QJ50-100/5 | 25 | 35 | 46-54 | 85-115 |
| 10" | 250QJ50-200/10 | 45 | 60 | 46-54 | 170-230 |
| 10" | 250QJ50-300/15 | 63 | 85 | 46-54 | 265-335 |
| 10" | 250QJ63-100/5 | 30 | 40 | 58-68 | 75-100 |
| 10" | 250QJ63-200/10 | 55 | 75 | 58-68 | 170-230 |
| 10“ | 250QJ63-300/15 | 90 | 120 | 58-68 | 205-343 |
| 10” | 250QJ80-100/5 | 37 | 50 | 74-86 | 85-115 |
| 10“ | 250QJ80-200/10 | 75 | 100 | 74-86 | 170-230 |
| 10" | 250QJ140-150/10 | 100 | 135 | 130-150 | 130-171 |
| 10" | 250QJ160-150/10 | 110 | 150 | 186-214 | 128-170 |
| 12" | 300QJ200-100/5 | 90 | 120 | 186-214 | 85-115 |
| 14" | 350QJ250-100/4 | 125 | 170 | 233-267 | 95-105 |
100m 200m 300m submersible pump specifications:
1. Diameter: 7 8 10 12 14 inch submersible pump
2. Flow: 10m3/h-250m3/h
3. Head: 100m 200m 300m submersible pump
4. Power: 9.2kw-125kw
5. Voltage: 380v/440v/480v/600v/660v/1140v
6. Material: Cast iron/stainless steel 304/316/316l/duplex stainless/904l
Customer Feedbacks:
Each single praise from customer, which ordered water submersible pump in APK factory , is our largest value. Our water submersible pump quality and service pay back. Realized the value of work. Also, we will service more and more customers in water submersible pump industry, making APK brand traveling the world.
However, if you would like to get qotation as soon as possible, please try to best message more specifications about your local site. Video or pictures will be more available. Some details need to be confirmed to choose water submersible pump models as below:
1. Flow rate/capacity: how much water pumping per hour or per liters?
2. Head meters
3. Water: clean water, sewage water, sea water or hot water
4. Installation: vertical or horizontal
