185kw Submersible Pump Farmland Irrigation Stainless Steel
Contact Person : Destiny.Huang
Phone Number : 86 17537187726
WhatsAPP : +8617537187726
Minimum Order Quantity : | 1 piece | Price : | E-mail or send an inquiry |
---|---|---|---|
Packaging Details : | Water submersible pump is packed in wooden box (EXPORT standard, more than 8mm thickness) according to the pumps' frame | Delivery Time : | 7-15 working days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 5000 pieces per month |
Place of Origin: | China | Brand Name: | APK |
---|---|---|---|
Certification: | CE; ISO; ABS | Model Number: | Submersible Pump |
Detail Information |
|||
Flow: | 230 M3/h Submersible Pump | Head: | 40 Meters Submersible Pump |
---|---|---|---|
Power: | 45kw 60hp Submersible Pump | Power Supply: | Electricity, 3phase 380v 50hz |
Pump Set Material: | Cast Iron | Wet Parts: | Stainless Steel |
Quality Warranty: | 24 Months | ODM OEM: | Acceptable |
Highlight: | 230M3/H Submersible Water Pumps,45kw Water Submersible Pump,40m Head Water Submersible Pump |
Product Description
Submersible pump from SLAPK is mainly for pumping clean water, sea water, sewage water, dirty water, waste water or hot water. Various submersible pump installation according to local site, vertical submersible pump, horizontal submersible pump and sled submersible pump.
We have exported different essentially submersible pump specifications for over sea marketing. For example, Indonesia customers would like to pumping clean water, applied for rice field farm.
We confirmed finally that the pumping water machine is submerged in water fully to running by electricity. We chose rice field water electric submersible pump type that can better meet real demands of customers. The Indonesia customer would like to 4 sets 230 cubic meters per hour and 40m lifting meter, one is applied his own ice field, the others is resale.
Submersible Pump Models:
1. Type: 250QJ230-40-45kw
2. Flow rate: 230m3/hr
3. Head meters: 40 meters
4. Power: 45kw 60hp
5. Power supply: electricity, 3phase 50hz
6. Pump set material: cast iron
7. Wet parts: stainless steel
8. Install: vertical
Considering that the cast iron submersible pump is submerged in river water fully, we suggest that submersible water pump matched motor sleeve if the river water with solid particles. Submersible pump for river water with motor sleeve, it is vital to accelerating motor cooling, cleaning drainage, filtering screen at the bottom of the casing to prevent solid particles from entering the pump body, protecting the pump finally.
It’s the most ordinary submersible water pump type for Zhengzhou Shenlong Pump Industry CO.,Ltd, 3-5 working days production.
10 Inch submersible pump specifications:
Note: Flow rate, head meters, voltage, frequency, material, all could be customized.
Pump Diameter | Model | Power | Flow range | Head range | Outlet Size | |
Inch (") | QJ type | kw | hp | m3/h | m | Inch(") |
10" | 250QJ50-20/1 | 5.5 | 7 | 46-54 | 17-23 | 3" |
10" | 250QJ50-60/3 | 15 | 20 | 46-54 | 51-69 | 3" |
10" | 250QJ50-120/6 | 30 | 40 | 46-54 | 102-138 | 3" |
10" | 250QJ50-200/10 | 45 | 60 | 46-54 | 170-230 | 3" |
10" | 250QJ50-240/12 | 55 | 75 | 46-54 | 204-276 | 3" |
10" | 250QJ50-300/15 | 63 | 85 | 46-54 | 265-335 | 3" |
10" | 250QJ50-340/17 | 75 | 100 | 46-54 | 315-375 | 3" |
10" | 250QJ50-380/19 | 90 | 120 | 46-54 | 350-410 | 3" |
10" | 250QJ50-400/20 | 100 | 135 | 46-54 | 365-430 | 3" |
10" | 250QJ63-40/2 | 11 | 15 | 58-68 | 34-46 | 3" |
10" | 250QJ63-60/3 | 18.5 | 25 | 58-68 | 51-69 | 3" |
10" | 250QJ63-120/6 | 37 | 50 | 58-68 | 100-138 | 3" |
10" | 250QJ63-160/8 | 45 | 60 | 58-68 | 130-184 | 3" |
10" | 250QJ63-260/13 | 75 | 100 | 58-68 | 220-299 | 3" |
10" | 250QJ63-300/15 | 90 | 120 | 58-68 | 205-343 | 3" |
10" | 250QJ80-20/1 | 7.5 | 10 | 74-86 | 17-23 | 4" |
10" | 250QJ80-140/7 | 55 | 75 | 74-86 | 118-163 | 4" |
10" | 250QJ80-200/10 | 75 | 100 | 74-86 | 170-230 | 4" |
10" | 250QJ80-240/12 | 90 | 120 | 74-86 | 204-276 | 4" |
10" | 250QJ80-280/14 | 110 | 150 | 74-86 | 235-325 | 4" |
10" | 250QJ100-36/2 | 15 | 20 | 80-120 | 32-42 | 4" |
10" | 250QJ100-72/4 | 30 | 40 | 80-120 | 64-84 | 4" |
10" | 250QJ100-144/8 | 63 | 85 | 80-120 | 120-168 | 4" |
10" | 250QJ100-216/12 | 100 | 135 | 80-120 | 190-252 | 4" |
10" | 250QJ125-16/1 | 9.2 | 13 | 116-134 | 13-19 | 5" |
10" | 250QJ125-128/8 | 75 | 100 | 116-134 | 109-147 | 5" |
10" | 250QJ125-192/12 | 110 | 150 | 116-134 | 163-220 | 5" |
10" | 250QJ140-180/12 | 125 | 170 | 130-145 | 156-205 | 5" |
10" | 250QJ160-15/1 | 13 | 18 | 148-172 | 44548 | 5" |
10" | 250QJ160-90/6 | 63 | 85 | 148-172 | 77-103 | 5" |
10" | 250QJ160-105/7 | 75 | 100 | 148-172 | 90-120 | 5" |
10" | 250QJ160-120/8 | 90 | 120 | 148-172 | 102-138 | 5" |
10" | 250QJ160-135/9 | 100 | 135 | 148-172 | 115-155 | 5" |
10" | 250QJ160-150/10 | 110 | 150 | 186-214 | 128-170 | 5" |
Zhengzhou Shenlong Pump Industry CO.,Ltd have stocked the general water submersible pump types or spare parts in warehouse workshops in order to provide better and more efficient service to our customers. Therefore, it's our promise to supply our products with favorable price, fast delivery, excellent quality and best services.
