100m3/H 15m Stainless Steel 304 Fountain Submersible Pump Lake Music Landscape

Minimum Order Quantity : 1 set Price : Please feel free to contact us
Packaging Details : Fountain submersible pump is packed with seaworthy export standard plywood case. Delivery Time : 7-15 working days after payment confirmation
Payment Terms : T/T, Western Union, L/C, MoneyGram, D/P, D/A Supply Ability : 5000 pieces per month
Place of Origin: China Brand Name: APK
Certification: ISO; CE; SGS; BV Model Number: Submersible Fountain Pump

Detail Information

Flow: 100m3/h Submersible Pump Head: 15m Submersible Pump
Power: 7.5 Kw Submersible Pump Feature: Rewinding
Install: Horizontal Material: Stainless Steel 304
High Light:

100m3/H Fountain Submersible Pump

,

Stainless Steel 304 Fountain Submersible Pump

,

15m Head Fountain Submersible Pump

Product Description



Australia 100m3/h 15m Stainless Steel 304 Fountain Submersible Pump Lake Music Landscape



Stainless steel 304 fountain pump models:

(Notice: flow rate, head meters, materials and installation, or any special specifications, ODM OEM is available)

Model Flow Head Power Current Max. Dia. Pump height Flange Dia. Discharge Dia.
QS Series m3/h m KW A mm mm mm mm
QS(P)15-14-1.1 15 14 1.1 3.2 156 520 156 50
QS(P)40-6-1.1 40 6 1.1 3.2 156 520 156 80
QS(P)25-9-1.1 25 9 1.1 3.2 156 520 156 65
QS(P)25-12-1.5 25 12 1.5 4.2 156 520 156 65
QS(P)40-9-1.5 40 9 1.5 4.2 156 520 156 80
QS(P)10-40/3-2.2 10 40 2.2 5.7 170 680 150 50
QS(P)15-26-2.2 15 26 2.2 5.7 170 580 150 50
QS(P)20-20-2.2 20 20 2.2 5.7 170 580 150 65
QS(P)25-17-2.2 25 17 2.2 5.7 168 580 150 65
QS(P)40-12-2.2 40 12 2.2 5.7 168 580 150 65
QS(P)65-7-2.2 65 7 2.2 5.7 168 580 150 90
QS(P)15-34/2-3 15 34 3 7 168 650 156 50
QS(P)10-54/3-3 10 54 3 7 170 680 150 50
QS(P)25-25-3 25 25 3 7 170 580 150 65
QS(P)20-30/2-3 20 30 3 7 168 650 156 65
QS(P)40-16-3 40 16 3 7 168 580 168 65
QS(P)50-13-3 50 13 3 7 168 580 168 90
QS(P)80-7-3 80 7 3 7 187 580 168 90
QS(P)65-10-3 65 10 3 7 168 580 168 90
QS(P)100-6-3 100 6 3 7 200 580 168 90
QS(P)100-65/5-4 10 65 4 10.2 168 750 150 50
QS(P)100-72/4-4 10 72 4 10.2 168 720 150 50
QS(P)10-81/6-4 10 81 4 10.2 168 780 150 50
QS(P)15-54/4-4 15 54 4 10.2 168 720 150 50
QS(P)20-40/2-4 20 40 4 10.2 168 730 168 65
QS(P)25-30/2-4 25 30 4 10.2 168 730 168 65
QS(P)30-30/2-4 30 30 4 10.2 168 730 168 65
QS(P)32-26-4 32 26 4 10.2 168 670 168 65
QS(P)40-21-4 40 21 4 10.2 168 630 168 65
QS(P)50-16-4 50 16 4 10.2 168 630 168 90
QS(P)65-13-4 65 13 4 10.2 168 630 168 90
QS(P)65-15-4 65 15 4 10.2 168 630 168 90
QS(P)80-12-4 80 12 4 10.2 187 630 168 90
QS(P)100-9-4 100 9 4 10.2 200 630 168 90
QS(P)100-95/7-5.5 10 95 5.5 13.4 187 1080 168 50
QS(P)10-108/8-5.5 10 108 5.5 13.4 187 1150 168 50
QS(P)15-65/5-5.5 15 65 5.5 13.4 187 960 168 50
QS(P)20-54/3-5.5 20 54 5.5 13.4 187 870 168 65
QS(P)25-40/3-5.5 25 40 5.5 13.4 187 870 168 65
QS(P)30-40/3-5.5 30 40 5.5 13.4 187 780 168 90
QS(P)40-30/2-5.5 40 30 5.5 13.4 187 780 168 90
QS(P)40-28-5.5 40 28 5.5 13.4 187 720 168 90
QS(P)50-26-5.5 50 26 5.5 13.4 187 780 168 90
QS(P)65-20-5.5 65 20 5.5 13.4 187 720 168 90
QS(P)65-18-5.5 65 18 5.5 13.4 187 720 168 90
QS(P)80-15-5.5 80 15 5.5 13.4 187 720 168 90
QS(P)100-12-5.5 100 12 5.5 13.4 200 720 200 125
QS(P)120-10-5.5 120 10 5.5 13.4 200 720 200 125
QS(P)220-5-5.5 220 5 5.5 13.4 200 720 200 150
QS(P)10-121/9-7.5 10 121 7.5 18.6 187 1250 168 50
QS(P)15-80/6-7.5 15 80 7.5 18.6 187 1200 168 50
QS(P)20-65/5-7.5 20 65 7.5 18.6 187 960 168 65
QS(P)20-75/4-7.5 20 75 7.5 18.6 187 1130 168 65
QS(P)25-65/5-7.5 25 65 7.5 18.6 187 960 168 65
QS(P)30-50/3-7.5 30 50 7.5 18.6 187 950 168 65
QS(P)30-54/3-7.5 30 54 7.5 18.6 187 950 168 65
QS(P)32-48/4-7.5 32 48 7.5 18.6 187 950 168 65
QS(P)40-40/2-7.5 40 40 7.5 18.6 187 820 168 90
QS(P)50-30/2-7.5 50 36 7.5 18.6 187 950 168 90
QS(P)50-36/3-7.5 50 36 7.5 18.6 187 950 168 90
QS(P)65-25-7.5 65 25 7.5 18.6 187 740 168 90
QS(P)80-22/2-7.5 80 22 7.5 18.6 187 820 168 90
QS(P)100-15-7.5 100 15 7.5 18.6 200 740 200 125
QS(P)100-17-7.5 100 17 7.5 18.6 200 740 200 125
QS(P)250-8-7.5 250 8 7.5 18.6 200 740 200 150



Stainless steel 304 fountain pump can be widely used in fountains, shallow well pumping, pool pumping, shallow well flushing, ground precipitation on construction sites, industrial and civil building water supply and drainage systems. It can also be used for water diversion and drainage in low-lying mountainous areas and non-explosive gas mines



Fountain water pump types:

Multistage deep well submersible pump for music fountain landscape:max flow rate is 2500m3/hr, max head meters is 600m

100m3/H 15m Stainless Steel 304 Fountain Submersible Pump Lake Music Landscape 0

Single stage submersible pump for music fountain landscape.

100m3/H 15m Stainless Steel 304 Fountain Submersible Pump Lake Music Landscape 1

Vertical and horizontal and diagonal installation, a great wealth of experience with various music fountain projects

100m3/H 15m Stainless Steel 304 Fountain Submersible Pump Lake Music Landscape 2

100m3/H 15m Stainless Steel 304 Fountain Submersible Pump Lake Music Landscape 3



FAQ

Q: How long is warranty?

A: About 24 months.



Q: How long is production lead time?

A: Depends on quantity, the normal small amount production is about 7-15 working days, maybe some fountain pump types are in stock.



Q: What’s types of shipping?

A: Usually by sea, and will be based on the customer's destination to choose the most favorable most appropriate way.



Q: What is the shipping terms to provide?

A: Depends on customer's requirements, we can provide different transportation terms, such as EXW, FOB, CIF, DDP. Or we deliver fountain pump to your own forwarder.



Q: How can I pay for my items? What is the payment you can provide?

A: Usually by T/T, 50% down payment once PI confirmed, the balance will be paid after inspection and before shipment.

     L/C at sight.
