IP68 protection of super flow drainage environmental cast iron pump

Minimum Order Quantity : 1 Price : 9999USD/unit
Packaging Details : Plywood as for export standard Delivery Time : 5-8 day work
Supply Ability : 2000units/month
Place of Origin: China Brand Name: SLAPK
Certification: CE Model Number: IP68 protection of super flow drainage environmental cast iron pump

Detail Information

Application: Dry And Submersible Pumps Flow: 120-510m3/h
Head: 3-50m Power: 2.2-380v
Material: Cast Iron Install: Vertical

Product Description



IP68 protection of super flow drainage environmental cast iron pump



Advantages of IP68 protection of super flow drainage environmental cast iron pump:



The vertical sewage pump with super large flow IP68 for protection, drainage and environmental protection is developed by our company on the basis of introducing high and new technology.

IP68 protection of super flow drainage environmental cast iron pump 0

Three outstanding features of IP68 protection of super flow drainage environmental cast iron pump:



1. High efficiency and energy saving



2. The power curve is flat, which can operate within the full lift range without overload



3. Single (double) large channel impeller is adopted, which has no blockage and good anti winding performance, and can smoothly transport long fibers containing large solid particles, food plastic bags or other suspended liquids. The maximum solid particle diameter that can be pumped is 80~250mm, and the fiber length is 300~1500mm

IP68 protection of super flow drainage environmental cast iron pump 1

Specification of IP68 protection of super flow drainage environmental cast iron pump:



Medium Temperature 0~40℃
Medium Agricultural irrigation, aquaculture water, river water.
Maximum depth in use 30m
Pump Structure Impeller 3HP,5HP:Centrifugal type;7.5HP,10HP: axial-flow type;15HP,20HP: Inclined flow
Seal
  • Double group mechanical seal
Bearing Deep groove ball bearing
Material outer cover Stainless steel
On the inside cover Cast iron
Housing Cast iron
Impeller bronze
sealed chamber Cast iron
bearing pedestal Cast iron
Motor Type Dry submersible
Pole 4P
insulation F
frequency 50HZ
Material Motor case Stainless steel
Cable H07RN-F


IP68 protection of super flow drainage environmental cast iron pump 2

WLT-150 type Technical parameters Environmental Protection Pumps:





Model Power Flow range Head range
WLT type kw hp m3/h m
WLT-150 3.7 5 120 5




IP68 protection of super flow drainage environmental cast iron pump 3

Technical  parameters  Environmental Protection Pumps:



Model Power Flow range Head range
WLT type kw hp m3/h m
WLT-63 2.2 3 120 3
WLT-150 3.7 5 120 5
WLT-200 5.5 7.5 210 4
WLT-250 7.5 10 330 4
WLT-300 11 15 420 5
WLT-1220 15 20 510 6



IP68 protection of super flow drainage environmental cast iron pump 4

We produce various types of protective drainage environmental protection pumps. If you have any questions about the pumps, please contact us. Our email is enquiry02@apkpump.com Our Whatsapp is+86 17537187726.



IP68 protection of super flow drainage environmental cast iron pump 5IP68 protection of super flow drainage environmental cast iron pump 6
