Submersible Water Pump 100m Head 3 Phase High Pressure Pump for Agricultural Irrigation

Product Description

Submersible Water Pump 100m Head 3 Phase High Pressure Pump for Agricultural Irrigation

In the modern agricultural sector, consistent access to water is the backbone of a successful harvest. For farms relying on deep groundwater sources, standard pumps often fall short. The Submersible Water Pump for Deep Well Borehole with a 100m Head is a robust, high-pressure solution designed specifically to bridge the gap between deep aquifers and thirsty crops. Powered by a 3-phase electric motor, this pump delivers the reliability and force needed for extensive irrigation systems.

Why Choose a 3-Phase Submersible Pump for Irrigation?

When dealing with deep boreholes and high-volume water transfer, 3-phase power offers distinct advantages over single-phase alternatives:
Higher Efficiency: Three-phase motors provide a more constant torque with less vibration, resulting in smoother operation and lower energy consumption over long running hours.

Greater Durability: These motors run cooler and are less prone to overheating, a critical feature for continuous irrigation cycles during peak growing seasons.
Stable Performance: In rural areas where power quality can fluctuate, 3-phase pumps are generally more robust and offer better starting torque without requiring large capacitors that can fail.

Key Features: 100m Head & High Pressure

The defining characteristic of this pump is its impressive 100-meter (approx. 328 feet) head capability. This high-pressure output is achieved through a multistage centrifugal design, where a series of precision-engineered impellers stack vertically to build pressure incrementally.

1. Deep Well Extraction
Designed for boreholes with diameters of 4 inches (100mm) or larger, this pump can easily lift water from depths where surface pumps are ineffective. The 100m head ensures that even after lifting water to the surface, there is sufficient residual pressure to drive irrigation equipment.

2. High-Pressure Output for Sprinklers
Modern irrigation methods, such as sprinkler guns and drip irrigation systems, require significant pressure to function correctly. This high-pressure pump eliminates the need for booster pumps on the surface, directly pressurizing your irrigation network from the well.

3. Premium Construction Materials
To withstand the harsh environment of a deep well, including potential abrasion from sand and corrosion from minerals:
Stainless Steel Body (AISI 304/316): Resists rust and corrosion, ensuring a long service life.
Durable Impellers: Often made from high-grade thermoplastic (Noryl) or stainless steel to resist wear from sediment.
Hermetically Sealed Motor: Oil-filled or water-filled designs ensure excellent cooling and protection against water ingress.

Ideal Applications in Agriculture
This specific pump configuration is versatile and supports various agricultural needs:
Large-Scale Crop Irrigation: Perfect for powering center pivots or extensive sprinkler lines across large fields.
Drip Irrigation Systems: Provides the constant pressure required to maintain uniform flow rates through miles of drip tape.
Livestock Water Supply: Reliably fills elevated storage tanks to ensure water availability for cattle and poultry farms.
Orchard Management: Delivers water to hillside orchards where lifting capability is crucial.

Technical Specifications
While specific models vary, a standard 100m Head 3-Phase Pump typically features:
Voltage: 380V - 415V (50Hz/60Hz)
Head Max: 100m - 120m
Flow Rate: Optimized for 10 - 60 m³/h depending on the motor power (kW).
Motor Power: Typically ranges from 4kW (5.5HP) to 15kW (20HP).
Outlet Diameter: 2" to 4" (Standard NPT or Flange).
Installation & Maintenance Tips

To maximize the lifespan of your investment:
Use a Control Box: Always install a control panel with overload, under-voltage, and dry-run protection.
Check Rotation: Ensure the 3-phase motor is rotating in the correct direction during installation to prevent reduced flow and impeller damage.
Cable Selection: Use waterproof, submersible-grade drop cables sized correctly for the depth to prevent voltage drop.

The Submersible Water Pump for Deep Well Borehole (100m Head, 3 Phase) is more than just a pump; it is a critical asset for agricultural productivity. By combining high-pressure capability with the efficiency of 3-phase power, it ensures that your crops receive the water they need, regardless of the depth of your water source.
