600 m³/h Large Flow Submersible Pump with 75kW Motor and SS304 Impeller

MOQ: 1 set
Price: Please feel free to contact us
Standard Packaging: Deep well submersible pump is packed by wooden case or as your request.
Delivery Period: 2-5 working days after payment confirm
Payment Method: L/C,D/A,D/P,T/T,
Supply Capacity: 8563 sets per month
Detail Information
Product Description
Detail Information
Place of Origin
Henan, China
Brand Name
SLAPK
Certification
ISO;CE,BV; TUV; CCC; SGS; SASO
Model Number
QJ
ODM/OEM:
Accept
Motor Power:
37kw 50hp
Volatge:
380v/440v/660v Or As Your Request
Frequency:
3 Phase 50hz/60hz
Flow:
18-214m3/h
Head:
35-388m
Pump Material:
Cast Iron/Stainless Steel
Pump Diameter:
7 8 10 12 Inches
Highlight:

600 m³/h Submersible Pump

,

75kW Submersible Water Pump

,

SS304 Large Flow Submersible Pump

Product Description
600 m³/h 75kW Large Flow Cast Iron Submersible Pump with SS304 Impeller

This large flow submersible pump is designed for large-scale water supply, agricultural irrigation, industrial water transfer, water conservancy projects and large drainage applications.

Design Operating Conditions
Flow Rate 600 m³/h
Head 28 m
Motor Power 75 kW
Voltage 380 V
Frequency 50 Hz
Power Supply 3 Phase
Motor 4 Pole
Pump Body Cast Iron
Impeller SS304 Stainless Steel

This configuration is suitable for pumping systems requiring high flow and moderate head.

600 m³/h Large Flow Capacity

With a design flow rate of 600 m³/h, this submersible pump is intended for large-scale water transfer and drainage systems.

A flow rate of 600 m³/h is suitable for applications such as:

  • Large-scale agricultural irrigation
  • River water intake
  • Reservoir water transfer
  • Reservoir drainage
  • Industrial water supply
  • Industrial circulating water
  • Municipal water supply and drainage
  • Large aquaculture projects
  • Construction dewatering
  • Water conservancy projects
For large-flow applications, pump selection should consider not only the required flow rate but also pipeline length, pipe diameter, valves, elbows and elevation difference.
28 m Pumping Head

The pump is designed for a 28 m head, making it suitable for high-flow, moderate-head pumping systems.

The actual total dynamic head is not simply the vertical lifting height. It also includes friction losses and local losses throughout the piping system.

Total Head = Static Head + Pipeline Friction Loss + Local Losses

If the actual operating requirement is close to 600 m³/h @ 28 m, this 75kW configuration can be considered as a reference solution. Final pump selection should be confirmed according to the actual pump performance curve and system conditions.
Cast Iron Pump Body

The pump body is manufactured from cast iron, providing good mechanical strength and structural stability.

Cast iron is widely used in large industrial pumps, irrigation pumps, water conservancy pumps and drainage pumps.

For clean water, river water and general irrigation water applications, cast iron is a commonly selected pump material that provides a practical balance between structural strength and project cost.

SS304 Stainless Steel Impeller

The impeller is one of the main hydraulic components of a water pump. This pump uses an SS304 stainless steel impeller, which provides better corrosion resistance than conventional cast iron impellers in many general water applications.

The SS304 impeller is suitable for applications including:

  • Clean water pumping
  • River water intake
  • Agricultural irrigation
  • Reservoir water supply
  • Industrial water supply
  • General circulating water systems
For seawater, high-chloride liquids or strongly corrosive fluids, the compatibility of SS304 with the actual pumped medium should be confirmed before ordering.
75kW 4-Pole Submersible Motor

The pump is equipped with a 75kW 4-pole three-phase submersible motor.

Standard Electrical Configuration

3 Phase / 380V / 50Hz / 75kW / 4 Pole

The 4-pole motor configuration can be applied to specific large-flow pump operating conditions according to the hydraulic design of the pump and impeller.

The actual motor speed, starting method, cable specification and motor protection system should be confirmed according to the final technical configuration.
Product Advantages
  • Large 600 m³/h Flow - Suitable for large-scale water transfer, irrigation and drainage projects
  • 28 m Head - Designed for high-flow and moderate-head pumping applications
  • 75kW 4-Pole Motor - Configured with a 75kW, 4-pole, 3-phase 380V 50Hz submersible motor
  • Cast Iron Pump Body - Provides good structural strength for general water pumping applications
  • SS304 Stainless Steel Impeller - Provides improved corrosion resistance for clean water applications
  • Submersible Installation - Allows direct underwater installation and reduces space requirements
